| SE/30 Boot Problem | |
| Posted by: mooxitani on 2021-11-20 06:34:36 Hi everyone, I recently picked up an SE/30 that was working when I originally powered it on, but it is now displaying strange symptoms. When powering the machine on, it either gets to the no floppy screen but restarts and proceeds to play the startup chime multiple times in a row. It sometimes also will just show a white screen with crackling coming out of the speaker. I assume this machine just needs a recap and cleaning, but could this also be an issue with the power supply? I was using it to test hard drives when it died, so maybe that caused the problem. Thanks in advance. | |
| Posted by: cheesestraws on 2021-11-20 06:45:45 'Restarting on its own' can definitely be a power supply problem. Check the voltages it's producing - you can do that at the external floppy port without having to muck about inside the machine. You're going to need to recap and clean the rest of the machine anyway, of course... | |
| Posted by: mooxitani on 2021-11-20 07:16:55 I can’t seem to get my meter to pick up the voltages on the floppy connector (I think the leads are too big). Do you know the pinout of the motherboard connecter? I might have better luck there. | |
| Posted by: mooxitani on 2021-11-20 07:37:11 I just tried the board in my working SE, and it exhibited the same problems- so it looks like it is a problem with the board. | |
| Posted by: dochilli on 2021-11-20 08:35:41 Use paperclips to check the voltages at the floppy port. Here you can see the pinout.
Macintosh 128K Voltage SettingLast week I opened up my Macintosh 128K to solve the issue of the screen going black after booting, leaving only the mouse pointer visible. I found that the two dials for screen brightness and height (or width, the one next to it) had some corrosion in them and turning them would solve the...
forums.macrumors.com
| |
| Posted by: mooxitani on 2021-11-20 08:55:26 I just gave the board an alcohol bath and it is back to working again. Looks like the problem was caps after all. | |
| Posted by: Nixontheknight on 2021-11-21 14:08:46 Amiga of Rochester (how do I tag users in a post) should be able to recap the board for you | |
| Posted by: mooxitani on 2021-11-21 14:45:44 He already is going to! | |
Posted by: mg.man on 2021-11-21 15:47:30how do I tag users in a postUse an "@" then their user name = @Amiga of Rochester | |
Posted by: Nixontheknight on 2021-11-26 17:24:05Use an "@" then their user name = @Amiga of Rochesterah ok | |
